Description
Active speaker with 12″ woofer, 1,35″ driver, 60 W RMS HF, 300 W RMS LF
- Active 12/2 full range system for mobile live and DJ applications
- DSP-controlled biamp amplifier (LF class D, HF class A/B)
- 24-bit DSP with adjustable high-pass filter, parametric 3-band EQ and signal delay
- Built-in Bluetooth player for audio streaming from compatible Bluetooth devices such as smartphones, tablets and notebooks
- 2-way bass-reflex enclosure with 30 cm woofer and 3.5 cm titanium driver
- 2 mic/line inputs (XLR/6.3 mm jack) with separate level controls
- Control via Bluetooth
- LCD display
- Digital signal processor
- Black metal grille with acoustic foam
- 3 Rugged carrying handles
- Application possibility: Standing; monitoring; on stand
- DSP presets: LIVE; MUSIC; SPEECH; DJ; TRIPOD; MONITOR; WALL
- For application areas such as: Mobile use; rental; sports centres/gyms; mobile djs / entertainer
Package contents
- 1 x compact cabinet speaker, 1 x power cord, 1 x user manual, 1 x declaration of conformity
| Power supply: | 100-240 V AC, 50/60 Hz |
| Power consumption: | 800 W |
| Protection class: | Protection class I |
| Power connection: | Mains input via IEC connector (M) mounting version power supply cord with safety plug (provided) |
| Power: | Program: 600W Rated: 60W RMS HF Rated: 300W RMS LF |
| Frequency range: | 55 – 20000 Hz |
| Sensitivity: | 95 dB |
| DSP: | Digital signal processor |
| DSP presets: | LIVE; MUSIC; SPEECH; DJ; TRIPOD; MONITOR; WALL |
| Control: | Bluetooth |
| Bluetooth device name: | Omnitronic |
| Attachment system: | Flange: Ã 35mm |
| Circuitry: | Class D Biamp |
| Display type: | LCD display |
| Control elements: | Master control, encoder |
| Controls: | Limiter |
| Status LED: | Power, signal, limit |
| Connections: | Output: line via 1 x 3-pin XLR |
| Input channels: | 2 x mono with mic-line switch via Combination socket (XLR/jack), channel control via rotary dial |
| Equalizer: | Master: 1 x 3-band tone control |
| Speaker: | 1 x woofer 12″ Voice coil lows 2,4″ with ferrit magnet Voice coil compression tweeter highs 1,35″ |
| Type of speaker: | Compact cabinet speaker |
| Type of construction: | Vented |
| Carrying handle: | 3 pc/pcs |
| Material: | Plastic |
| Color: | Black |
| Dimensions: | Width: 38 cm Depth: 35 cm Height: 61 cm |
| Weight: | 15,45 kg |
Additional information
| Dimensions | 0,4400 × 0,4000 × 0,6800 cm |
|---|---|
