Beschrijving
1820 W fog machine with LED illumination, vertical & horizontal operation
- Output nozzle with RGBAW LED illumination for impressive effect presentations
- Vertical and horizontal fog output possible
- New housing design allows upward and downward fog output
- Optional W-DMX receiver for wireless DMX control
- Control via integrated DMX interface or user-friendly control panel
- Adjustable timer with interval, duration and output volume
- Continuous activation via handy transmitter
- Operates on standard water-based fluid
- Large fluid tank compartment, fluid level indication
- DMX interface with 3- and 5-pin connectors
- Rugged metal housing
- 27 powerful LEDs 8 W high-power 5in1 PCL RGBWA (homogenous color mix)
- Output distance: Approx. 10 m
- 8 integrated Showprograms
- Direct color selection for 25 preset colors
- Can be operated in 10; 15; 25 CH mode
- Controlling by Wireless remote control; W-DMX by wireless solution (optional); DMX; Master/slave function; Timer
- Wireless remote control: Operating range up to 50m
- Built with NEUTRIK connector
- For application areas such as: Lender; mobile use; Stage
Package contents
- 1 x device, 1 x user manual, 1 x power cord, 1 x remote control, 1 x declaration of conformity, 1 x container, 2 x tube
| Power supply: | 230 V AC, 50 Hz |
| Power consumption: | 1670 W |
| IP classification: | IP20 |
| Power connection: | Mains input via PowerCON TRUE (M) mounting version power supply cord with safety plug (provided) |
| LED: | 27 x 8 W high-power 5in1 PCL RGBWA (homogenous color mix) |
| Warm-up time: | Approx. 14 min |
| Output distance: | Approx. 10 m |
| Tank capacity: | 6 l Smoke fluid |
| Fluid consumption: | Approx. 400 ml/min |
| DMX channels: | 10; 15; 25 |
| DMX input: | 3-pin XLR (M) mounting version 5-pin XLR (M) mounting version |
| DMX output: | 3-pin XLR (F) mounting version 5-pin XLR (F) mounting version |
| Control: | Wireless remote control; W-DMX by wireless solution (optional); DMX; Master/slave function; Timer |
| Housing color: | Black |
| Carrier frequency: | 433,92 MHz |
| Range: | Wireless remote control: range up to 50m |
| Use of brands: | Built with NEUTRIK connector |
| Color: | Black |
| Dimensions: | Width: 32,1 cm Depth: 39,3 cm Height: 42 cm |
| Weight: | 24,85 kg |
Extra informatie
| Afmetingen | 0,5480 × 0,4750 × 0,5680 cm |
|---|---|
| Levertijd | 1 dag |
